What is an SRV record and which services use it?

An SRV (service) record is a DNS record that tells clients which host and port provide a particular service for a domain. Where an A record only gives an IP address and an MX record only works for email, an SRV record can describe any service: it names the service and protocol, gives a hostname and port number, and adds priority and weight values so clients can fail over between servers and spread the load. Defined in RFC 2782, it's used by VoIP, chat, directory services, calendars, game servers, and databases, among others.

SRV records let you move a service to a different server or port without reconfiguring every client, as long as the client software supports SRV lookups. In this article you'll learn how SRV records are named and structured, how priority and weight work together, which services actually use them and the names they expect, how to create and query SRV records, and the limitations to be aware of, including why web browsers don't use them.

How an SRV Record Is Structured

An SRV record has a special naming format and four data fields:

_sip._tcp.example.com.    3600    IN    SRV    10 60 5060 sip1.example.com.

The Name: _service._protocol.domain

The record name is built from three parts:

• _sip: The symbolic name of the service, with a leading underscore.
• _tcp: The transport protocol, usually _tcp or _udp. Some services use _tls as well.
• example.com.: The domain the service belongs to.

The underscores keep these names from clashing with real hostnames, which can't contain underscores. A client that wants to find the SIP service for example.com over TCP knows to look up exactly _sip._tcp.example.com.

The Data Fields

Field	Example	Meaning
Priority	10	Lower values are tried first, like MX priority
Weight	60	Relative share of traffic among records with the same priority
Port	5060	The TCP or UDP port the service listens on
Target	sip1.example.com.	The hostname of the server providing the service

All three numbers are 16-bit values from 0 to 65535. The target must be a hostname with its own A or AAAA records. It mustn't be a CNAME, and it can't be an IP address.

A target of a single dot (.) has a special meaning: the service is deliberately not available at this domain. That lets clients stop looking instead of trying fallbacks.

_xmpp-server._tcp.example.com.    3600    IN    SRV    0 0 0 .

How Priority and Weight Work Together

Priority and weight solve two different problems.

Priority for Failover

A client always tries the records with the lowest priority first. It only moves to the next priority level when every server at the current level has failed:

_sip._tcp.example.com.  3600  IN  SRV  10 50 5060 sip1.example.com.
_sip._tcp.example.com.  3600  IN  SRV  10 50 5060 sip2.example.com.
_sip._tcp.example.com.  3600  IN  SRV  20 0  5060 sip-backup.example.net.

Here sip1 and sip2 share the work, and sip-backup only receives traffic if both are down.

Weight for Load Distribution

Among records with the same priority, the client picks one at random in proportion to its weight. With weights of 60 and 40, roughly 60% of clients choose the first server and 40% the second:

_sip._tcp.example.com.  3600  IN  SRV  10 60 5060 big.example.com.
_sip._tcp.example.com.  3600  IN  SRV  10 40 5060 small.example.com.

Weights are relative, so 60 and 40 behave the same as 3 and 2. A weight of 0 means the record should be chosen only very rarely when other records at that priority have higher weights. If you don't need weighting, give every record the same value.

The Selection Algorithm in Code

RFC 2782 describes exactly how clients should order records. This Python script uses dnspython to look up SRV records and order them the way a compliant client would:

import random
import sys

import dns.resolver


def weighted_order(records):
    """Order same-priority records using the RFC 2782 weighting method."""
    remaining = sorted(records, key=lambda r: r.weight)  # zero weights first
    ordered = []
    while remaining:
        total = sum(r.weight for r in remaining)
        pick = random.randint(0, total)
        running = 0
        for record in remaining:
            running += record.weight
            if running >= pick:
                ordered.append(record)
                remaining.remove(record)
                break
    return ordered


def srv_order(name):
    answers = dns.resolver.resolve(name, "SRV")
    by_priority = {}
    for record in answers:
        by_priority.setdefault(record.priority, []).append(record)

    result = []
    for priority in sorted(by_priority):
        result.extend(weighted_order(by_priority[priority]))
    return result


if __name__ == "__main__":
    name = sys.argv[1] if len(sys.argv) > 1 else "_sip._tcp.example.com"
    for r in srv_order(name):
        target = str(r.target)
        if target == ".":
            print("Service explicitly not available")
            break
        print(f"priority={r.priority:<5} weight={r.weight:<5} {target}:{r.port}")

pip install dnspython
python srv_order.py _sip._tcp.example.com

priority=10    weight=60    big.example.com.:5060
priority=10    weight=40    small.example.com.:5060
priority=20    weight=0     sip-backup.example.net.:5060

Run it a few times and the order within priority 10 will change in roughly a 60/40 split.

Which Services Use SRV Records?

SRV records only help if the client software looks them up. These are the most common services that do, along with the names they expect.

VoIP and SIP

SIP phones and softphones use SRV records (RFC 3263) to find the SIP server for a domain, so users can sign in with just alice@example.com:

_sip._udp.example.com.   3600  IN  SRV  10 50 5060 sip.example.com.
_sip._tcp.example.com.   3600  IN  SRV  10 50 5060 sip.example.com.
_sips._tcp.example.com.  3600  IN  SRV  10 50 5061 sip.example.com.

XMPP Chat

XMPP (RFC 6120) uses separate records for client connections and for server-to-server federation:

_xmpp-client._tcp.example.com.  3600  IN  SRV  5 0 5222 chat.example.com.
_xmpp-server._tcp.example.com.  3600  IN  SRV  5 0 5269 chat.example.com.

Active Directory and Kerberos

Windows domains depend heavily on SRV records. Domain-joined computers find domain controllers, Kerberos servers and global catalogue servers through records that the domain controllers register automatically in DNS:

_ldap._tcp.dc._msdcs.corp.example.com.  600  IN  SRV  0 100 389  dc1.corp.example.com.
_kerberos._tcp.corp.example.com.        600  IN  SRV  0 100 88   dc1.corp.example.com.
_gc._tcp.corp.example.com.              600  IN  SRV  0 100 3268 dc1.corp.example.com.

When computers can't find a domain controller, missing or stale SRV records are one of the first things to check. On a Windows machine, nltest /dsgetdc:corp.example.com uses the same lookups.

Calendars and Contacts

CalDAV and CardDAV clients (RFC 6764) can discover servers through SRV records, often paired with a TXT record that gives the path:

_caldavs._tcp.example.com.   3600  IN  SRV  0 1 443 dav.example.com.
_carddavs._tcp.example.com.  3600  IN  SRV  0 1 443 dav.example.com.
_caldavs._tcp.example.com.   3600  IN  TXT  "path=/dav/calendars"

Email Client Configuration

RFC 6186 and RFC 8314 define SRV records that let mail apps discover IMAP and submission servers. Support varies by client, but publishing them does no harm:

_imaps._tcp.example.com.        3600  IN  SRV  0 1 993 imap.example.com.
_submissions._tcp.example.com.  3600  IN  SRV  0 1 465 smtp.example.com.
_submission._tcp.example.com.   3600  IN  SRV  0 1 587 smtp.example.com.

Microsoft Outlook also checks _autodiscover._tcp as one of its fallback methods for finding the Autodiscover service.

Game Servers

Minecraft Java Edition looks up _minecraft._tcp, which lets players connect to play.example.com even when the server runs on a non-default port:

_minecraft._tcp.play.example.com.  3600  IN  SRV  0 5 25570 mc1.example.com.

Databases and Platforms

• MongoDB: Connection strings beginning mongodb+srv://cluster0.example.com make the driver look up _mongodb._tcp.cluster0.example.com to find every member of the cluster, plus a TXT record for connection options.
• Matrix: Homeservers find each other for federation through _matrix-fed._tcp, with .well-known files as the preferred method.
• Kubernetes: Cluster DNS creates SRV records for named ports on services, such as _http._tcp.my-svc.my-namespace.svc.cluster.local.

Why Browsers Don't Use SRV Records

It's a common wish to publish _http._tcp.example.com and run a website on port 8080 without the port appearing in the URL. Unfortunately, web browsers don't look up SRV records for HTTP. HTTP was standardised long before SRV, and browser vendors never adopted it because of the extra lookup latency and backwards-compatibility concerns.

The modern answer for web traffic is the HTTPS DNS record type, which can advertise alternative ports and protocols and which major browsers do support. For everything else, check the documentation of the client software. If it doesn't mention SRV, assume it doesn't use it.

Creating SRV Records

In a Zone File

$ORIGIN example.com.
_sip._tcp        3600  IN  SRV  10 60 5060 sip1.example.com.
_sip._tcp        3600  IN  SRV  10 40 5060 sip2.example.com.
sip1             3600  IN  A    192.0.2.21
sip2             3600  IN  A    192.0.2.22

In a Web Dashboard

Many DNS provider dashboards split an SRV record into separate fields: service, protocol, name, priority, weight, port and target. Others ask for a full record name such as _sip._tcp and a combined value such as 10 60 5060 sip1.example.com. If the dashboard appends your domain automatically, enter only _sip._tcp as the name, or you'll end up with _sip._tcp.example.com.example.com.

With the AWS CLI on Route 53

Route 53 expects the value as a single string of priority, weight, port and target:

cat > srv.json <<'EOF'
{
  "Changes": [
    {
      "Action": "UPSERT",
      "ResourceRecordSet": {
        "Name": "_sip._tcp.example.com",
        "Type": "SRV",
        "TTL": 3600,
        "ResourceRecords": [
          { "Value": "10 60 5060 sip1.example.com" },
          { "Value": "10 40 5060 sip2.example.com" }
        ]
      }
    }
  ]
}
EOF

aws route53 change-resource-record-sets \
  --hosted-zone-id Z0123456789EXAMPLE \
  --change-batch file://srv.json

Querying SRV Records

With dig

dig _sip._tcp.example.com SRV +noall +answer

_sip._tcp.example.com.  3600  IN  SRV  10 60 5060 sip1.example.com.
_sip._tcp.example.com.  3600  IN  SRV  10 40 5060 sip2.example.com.

Authoritative servers often include the targets' A and AAAA records in the additional section, saving the client a second lookup. You can see them by dropping +noall +answer.

With nslookup

nslookup -type=srv _sip._tcp.example.com

_sip._tcp.example.com   service = 10 60 5060 sip1.example.com.
_sip._tcp.example.com   service = 10 40 5060 sip2.example.com.

With PowerShell

Resolve-DnsName -Name _ldap._tcp.dc._msdcs.corp.example.com -Type SRV

Testing the Port

Once you know the target and port, check that the service is actually listening:

nc -vz sip1.example.com 5060

A DNS record pointing at a closed port looks correct in every DNS tool but still fails for users.

Common SRV Record Mistakes

1. Missing underscores: sip.tcp.example.com isn't an SRV name. It must be _sip._tcp.example.com.
2. Doubling the domain: Dashboards that append the zone name can turn _sip._tcp.example.com into _sip._tcp.example.com.example.com. Query the record to confirm the final name.
3. Pointing the target at a CNAME or an IP: The target must be a hostname with address records.
4. Wrong protocol label: Publishing _udp when the client looks for _tcp, or the other way round.
5. Expecting browsers to use it: SRV records don't change how websites load.
6. Forgetting the firewall: The record advertises a port, but the port still has to be open.

---

FAQ: SRV Records

---

Conclusion

An SRV record combines a service name, a protocol, a hostname and a port into a single DNS entry, with priority and weight values that give you failover and load sharing. It lets clients find a service from nothing more than a domain name, which is why VoIP, XMPP, Active Directory, CalDAV, Minecraft and MongoDB all rely on it.

The catch is that SRV records only work for clients that look them up, so always confirm support before you rely on them. Get the underscore naming right, point targets at real hostnames, and test both the DNS record and the port itself after every change.
